Features
It’s the years slugging it out in the city that made the original Lombard such a capable beast on the city asphalt but we found that these commutes often included regular dirt-detours, which, over time, evolved the Lombard into the multi-surface machine it is today. That very tough and fast urban rig just got even faster with the addition of a Bosch SX Sprint power unit and a fully integrated 400W/h powertube battery. The frame now utilizes our all-new Series 4 Beyond Road Aluminum frameset and full carbon fork with tapered steerer.
Durable components including high volume tires and hydraulic disc brakes and the option for wireless Shimano gearing and dropper seat posts make the new Lombard E a serious force to be reckoned with!
Specs
- Range: 22-137km
- Motor: Bosch SX Sprint, 250W, 55Nm, Class 1 32km/h
- Battery: Bosch Compact Power Tube 400, 400Wh
- Fork: Marin Full Carbon w/ Tapered Steerer, 12mm Thru-Axle, Flat-Mount Disc, Fender Eyelets
- Frame: All-New Series 4 Beyond Road E, 6061 Aluminum, One-Piece Hydroformed Downtube & Motor Mount, Internal Cable Routing, Mudguard and Rack Mounts, Flat Mount Disc, 142x12mm Thru-Axle
- Rear Hub: Forged Aluminum Alloy, 142x12mm, Disc, 32H
- Front Hub: Forged Aluminum Alloy, 100x12mm, Disc, 32H
- Rim: Marin Aluminum Double Wall, 25mm Inner, 18mm Tall, Disc Specific, Tubeless Compatible
- Spokes: 14g Black Stainless Steel
- Tires: Vee Tire Co., G-Sport, 700x44, Tubeless Compatible
- Rear Derailleur: Shimano GRX RD-RX822, 12-speed, Clutch
- Shift Lever: Shimano GRX STRX610, 12-speed
- Crankset: Forged Alloy, 42T Steel Chainring
- Chain: KMC E12S
- Cassette: Shimano CSM6100, 10-51T
- Front Brakes: Shimano GRX RX400, Flat-Mount Hydraulic Disc, 160mm Rotor
- Rear Brakes: Shimano GRX RX400, Flat-Mount Hydraulic Disc, 160mm Rotor
- Brake Levers: Shimano GRX STRX610
- Handlebar: Marin Butted Alloy, Compact 16º Flared Drop
- Stem: Marin 3D Forged Alloy
- Grips: Marin Shock Absorbing Perforated Tape
- Headset: FSA No.42 ACB, Sealed Cartridge Bearings, 1 1/8” x 1 1/2”
- Seatpost: Marin Alloy, 27.2
- Saddle: Marin Beyond Road Concept Elite
- Extras: Removable kickstand mount
