SURLY

Bridge Club - Trevor's Closet Black

$2,299.00

In stock (1)

The Surly Bridge Club is for those multi-surface outings — planned or unplanned.

Color:

Size:

Add to compare Add to wishlist

SURLY Bridge Club - Trevor's Closet Black

Bridge Club - Trevor's Closet Black — "Color: Trevor's Closet Black","Size: XL"

Description

All Road Touring Bike for Any Destination

Bridge Club is for those multi-surface outings — planned or unplanned. We've all run out the clock on a dirt tour and had to add in some paved shortcuts. Conversely, when you’re feeling a little zesty on your next road tour, Bridge Club is ready for reroutes through the woods.

Some people hear "bike touring" and immediately think of long-forgotten stretches of highway, small-town oddities, and roadside attractions. Some instantly recall desolate stretches of desert dirt roads or lush green forest trails. With Bridge Club, you can have your dessert and eat it too!

Ultra-focused on simplicity, it only has the barnacles that matter most to the discerning bike tourist
Run racks and panniers, framebags, or all of the above
Disc brake-specific, single position vertical rear dropout makes it less intimidating than other bikes in the category
Clearance for 700 x 47mm tires (with or without fenders), 27.5 x 2.8” tires (27.5 x 2.6” with fenders), and 26 x 3” tires (26 x 2.8” with fenders)

Build Kit

Frame		Surly Bridge Club, 4130 Chromoly, Natch tubing, double-butted main triangle, TIG welded, ED coated
Color		Trevor's Closet Black
Fork		Surly Cocktail Fork, 4130 Chromoly, double-butted tapered fork blades, TIG welded, ED coated

Components

Headset		Cane Creek 40
Seatpost Clamp		Surly Stainless 30.0
Seatpost		Promax 27.2mm x 350mm, 12mm offset
Stem		Promax DA-296, 31.8mm
Grips/Bar Tape		Velo Black
Saddle		WTB Volt
Handlebar		Salsa Bend

Drivetrain

Front Derailleur		N/A
Rear Derailleur		Shimano CUES U6000 GS
Cassette		Shimano CUES LG400, 11-50T, 11-speed
Chain		KMC eGlide EPT
Crankset		Shimano CUES U6000, 32T
Shifter		Shimano CUES U6000
Bottom Bracket		Shimano BB-MT501

Brakes

Brake Levers		Tektro HD-M275/HD-M276
Rotors		Tektro 160mm (front & rear), 6-Bolt

Wheels & Tires

Front Tire		WTB Trail Boss 27.5 x 2.4", 27 TPI, Wire Bead
Rear Tire		WTB Trail Boss 27.5 x 2.4", 27 TPI, Wire Bead
Front Hub		Novatec, QR x 100mm, 6-bolt, 32h
Rear Hub		Novatec, QR x 141mm, 6-bolt, 32h
Spokes		14G Black
Rims		WTB ST i30 TCS 2.0, 27.5", 32h

Weight

Size		Complete Bike Weight
Medium		30 lb. 6 oz.

Geometry

Size	X-Small	Small	Medium	Large	X-Large
A. Effective Top Tube (mm)	545.0	570.0	595.0	615.0	630.0
B. Stand Over Height (mm)	709.0	750.5	780.0	812.0	845.5
C. Reach (mm)	376.0	397.0	419.0	434.5	444.0
D. Stack (mm)	553.0	567.0	576.0	590.0	609.0
E. Seat Tube Length (mm)	335.6	406.4	457.2	508.0	558.8
F. Headtube Length (mm)	110.0	120.0	130.0	145.0	165.0
G. Headtube Angle (°)	70.0	71.0	71.0	71.0	71.0
H. Seat Tube Angle (°)	73.0	73.0	73.0	73.0	73.0
I. BB Drop (mm)	60.0	60.0	60.0	60.0	60.0
K. Chainstay Length (mm)	435.0	435.0	435.0	435.0	435.0
L. Fork Length A-C (mm)	420.0	420.0	420.0	420.0	420.0
M. Fork Offset (mm)	45.0	45.0	45.0	45.0	45.0
N. Wheelbase (mm)	1032.0	1047.5	1073.0	1093.0	1109.0
Crank Arm Length (mm)	170.0	170.0	175.0	175.0	175.0
Handlebar Width (mm)	700.0	700.0	740.0	740.0	740.0
Stem Length (mm)	—	—	90.0	90.0	—
Recommended Rider Height (cm)	145–160	155–170	165–180	175–191	185–201

Frame Specs

Designed Wheel/Tire Size		27.5 x 2.4"
Alternate Tire/Wheel Clearance		Frame & Fork: • 26 x 3.0" (2.8" with fenders) • 27.5 x 2.8" (2.6" w/fenders) • 700c x 47mm (w/ or w/o fenders)
Frame Construction		4130 Chromoly, Natch tubing, double-butted main triangle, TIG welded, ED coated
Fork Construction		4130 Chromoly, Natch tubing, double-butted tapered blades, TIG welded, ED coated
Suspension Fork Compatible		No (rigid only)
Rigid Fork Length (A-C)		420mm
Fork Offset		43mm
Front Axle Spacing		10 x 100mm QR
Rear Axle Spacing		"Gnot-Boost" 138mm (compatible with 10 x 135mm & 10 x 141mm QR)
Rear Brake Mount		51mm IS, Max rotor 203mm
Headset Type (Upper/Lower)		EC34/28.6 (upper), EC34/30 (lower)
Steerer Tube		1-1/8" (Ø28.6mm)
Crown Race		Ø30mm
Stem Clamp Diameter		Ø28.6mm (1-1/8")
Seatpost Diameter		Ø27.2mm
Dropper Post Compatible		No
Seatpost Clamp		Ø30mm (Surly Stainless included)
Front Derailleur Mount		Ø28.6mm clamp; high direct mount, top-pull; adapters required for offset spacing
BB Shell		73mm BSA threaded (1.37" x 24TPI)
Max Chainring Sizes		• 1x (MTB): 34T • 2x (MTB): 26/40T • 3x (MTB): 22/36/44T • 1x (Boost): 40T • 2x (Boost): 32/42T
Bottle Cage Mounts		• XS: 2 Three-Pack • S–XL: 1 Standard + 2 Three-Pack
Fork Mounts		2 Three-Pack, Rack Mounts (upper/lower/mid-blade threaded)
Front & Rear Fender Mounts		Yes
