Specification

Details

Frame Material

Kona Carbon

Sizes

48, 50, 52, 54, 56, 58

Rear Shock

n/a

Fork

Fox TC32 Performance GRIP damper, 40mm travel, Tapered, 100x12mm

Crankarms

SRAM Apex 1 DUB Wide

Chainrings

SRAM Apex 38t AL direct mount

Bottom Bracket (B/B)

SRAM Press-Fit 86.5 DUB Wide

Pedals

n/a

Chain

SRAM NX Eagle 12-speed

Cassette

SRAM PG-1230 11-50t 12-speed

Chainguide

n/a

Front Derailleur (F/D)

n/a

Rear Derailleur (R/D)

SRAM Apex 12 Eagle

Shifters

SRAM Apex 12

Brake Calipers

SRAM Apex Flat Mount Hydraulic

Front Brake Rotor

SRAM Centerline 6-bolt 180mm

Rear Brake Rotor

SRAM Centerline 6-bolt 180mm

Brake Levers

SRAM Apex 12

Headset

FSA Orbit No. 57E, ZS 44/56

Handlebar

Kona 20-degree flare, 48: 440mm; 50: 460mm; 52-54: 480mm; 56: 500mm; 58: 520mm

Stem

Kona 6-degree rise, 48-52: 40mm; 54-58: 50mm

Seatpost

TranzX Dropper +RAD Internal, 31.6mm, 125mm travel

Seat Clamp

Kona 34.9mm

Grips

Velo bar tape

Saddle

WTB Volt Medium Steel SL

Front Hub

Formula 100 x 12 6-bolt

Rear Hub

Formula 142 x 12 6-bolt, 11-speed Road freehub

Spokes

Stainless Black 14g

Rims

WTB KOM Team i27 700c 32h

Front Tire

Maxxis Ravager 700 x 50 TR EXO

Rear Tire

Maxxis Ravager 700 x 50 TR EXO

Paint Color

Gloss Metallic Blue w/ Metallic Silver Decals

Geometry

48

50

52

54

56

58

Seat Tube (ST) Length

410

410

455

455

500

535

Top Tube (TT) Length

530

544

559

576

593

613

Reach

380

385

390

395

400

405

Stack

560

575

590

610

630

660

Standover

-

-

-

-

-

-

Head Tube (HT) Angle

69.5

69.5

69.5

69.5

69.5

69.5

Head Tube (HT) Length

115

131

147

172

193

225

Seat Tube (ST) Angle

75.0

74.5

74.0

73.5

73.0

72.5

Chainstay (CS) Length

445

445

445

445

445

445

Bottom Bracket (BB) Drop

75

75

75

72

72

72

Bottom Bracket (BB) Height

292

292

292

295

295

295

Wheelbase

1059

1069

1080

1094

1106

1123

Front Center

625

635

646

659

671

687

Fork Length

420

420

420

420

420

420

Fork Offset

55

55

55

55

55

55

Height (Inches)

Height (Metric)

Inseam (Inches)

Inseam (Metric)

Rove

Libre

Sutra/Ouroboros

Dews

CoCo

4'10"-5'1"

147-155 cm

24”-27”

61-69 cm

48 cm

50 cm

48 cm

N/A

XS

5'0"-5'3"

152-160 cm

26"-29"

66-74 cm

48-50 cm

50 cm

48-50 cm

Small

Small

5'2"-5'7"

157-170 cm

27"-30"

69-76 cm

48-52 cm

50-52 cm

48-52 cm

Small, Medium

Small, Medium

5'6"-5'10"

168-178 cm

29"-31"

74-79 cm

52-54 cm

52-54 cm

52-54 cm

Medium

Medium

5'9"-6'0"

175-183 cm

30"-33"

76-84 cm

52-56 cm

54-56 cm

54-56 cm

Medium, Large

Medium, Large

5'11"-6'2"

180-188 cm

32"-35"

81-89 cm

54-58 cm

54-58 cm

54-58 cm

Large, XL

Large

6'1"-6'5"

185-196 cm

33"-36"

84-91 cm

56-58 cm

58 cm

56-58 cm

XL

N/A
