A refined steel commuter that gives as much style as it does durability. With thru-axles front and rear for a smoother, more responsive ride, and external headset cups for that classic look, the Dr Dew is built to make every ride feel solid and sure-footed.

Specs

Frame: Kona Butted Cromoly
Sizes: S, M, L, XL
Rear Shock: n/a
Fork: Kona Cromoly
Crankset: Shimano CUES 6000 40t / S-M 170mm / L-XL 175mm
Bottom Bracket: Shimano BSA 73mm
Pedals: Feimin Platform
Chain: Shimano CUES LG500
Cassette: Shimano CUES 4000 11-50t 11spd
Chainguide: n/a
Front Derailleur: n/a
Rear Derailleur: Shimano CUES 6000
Shifter: Shimano CUES 6000
Brake Calipers: Shimano ALTUS
Front Brake Rotor: Shimano 180mm Centerlock
Rear Brake Rotor: Shimano 180mm Centerlock
Brake Levers: Shimano ALTUS
Headset: FSA Orbit No.1 EC34/EC34
Handlebar: Kona Back 10º / Up 6º / Rise 70mm / Width 700mm
Stem: Kona 31.8mm / Rise 3º / Length 45mm
Seatpost: Kona w/Offset 27.2mm / 375mm
Seat Clamp: Kona Clamp 31.8mm
Grips: Kona Key Grip
Saddle: Kona Commuter
Front Hub: Shimano 12x100mm
Rear Hub: Shimano 12x142mm
Spokes: Stainless 2.0mm Black
Rims: Double Wall Aluminum
Front Tire: WTB GROOV-E 29x2.0"
Rear Tire: WTB GROOV-E 29x2.0"
Paint Colour: Satin Algae w/ Aspen Decals
Extras: Bell / Kickstand
*All specifications are subject to change without notice.
